How to disconnect and remove the clutch master cylinder on Hyundai Accent?

Disconnect the negative cable from the battery. For 2011 and earlier models, raise the vehicle and support it securely on jackstands. Loosen the bleed plug on the release cylinder and place a drain pan under the bleeding plug. Apply the clutch pedal several times to force the hydraulic brake fluid out of the system. Continue to apply the clutch pedal until all fluid is expelled. Tighten the bleed plug securely. Caution: Don't allow hydraulic brake fluid to come into contact with paint as it will damage the finish. Disconnect the hydraulic line at the master cylinder. Have a small can and rags handy, as some residual fluid will be spilled as the line is removed. Working inside the vehicle, remove the cotter pin, washer, and clevis pin. Disconnect the pushrod from the clutch pedal. Working in the engine compartment, remove the nuts securing the master cylinder to the firewall and remove the master cylinder. For 2012 and later models, working in the vehicle under the dashboard, disconnect the push rod from the master cylinder by removing the snap pin and washer. Remove the four clutch pedal mounting nuts and pull the pedal assembly slightly forward. Remove the battery and the ECM. Working in the engine compartment, disconnect the release cylinder line and the reservoir hose from the clutch master cylinder. Remove the clutch master cylinder by turning it clockwise and pulling it from the firewall. Installation is the reverse of removal. Tighten the clutch master cylinder mounting bolts/nuts securely. Be sure to bleed the system.

Genuine Hyundai Accent Clutch Master Cylinder

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

13 Clutch Master Cylinders found

View related parts
Hyundai Accent Cylinder Assembly-Clutch Master
Part Number: 41610-1R100
$206.88 MSRP: $290.66
You Save: $83.78 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Master Cylinder
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2011-2017 Hyundai Accent | DOHC - GDI | Sedan - 4Door 5P, Sedan - 5Door 5P
View related parts
Hyundai Accent Clutch Master/Cylinder & Hose
Part Number: 41605-F9100
$57.67 MSRP: $80.32
You Save: $22.65 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Master Cylinder
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2018-2022 Hyundai Accent | DOHC - GDI, DOHC - MPI | Sedan - 4Door 5P
View related parts
Hyundai Accent Cylinder Assembly-Clutch Master
Part Number: 41610-25020
$206.88 MSRP: $290.66
You Save: $83.78 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Master Cylinder
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1999-2006 Hyundai Accent | Low Grade, Middle Grade | 3 Door Sedan, 4 Door Sedan
View related parts
Hyundai Accent Cylinder Kit-Clutch Master
Part Number: 41660-22A02
$76.46 MSRP: $104.95
You Save: $28.49 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1994-1999 Hyundai Accent | High Grade, Low Grade, Middle Grade | 3 Door, 4 Door
View related parts
Hyundai Accent Cylinder Assembly-Clutch Master
Part Number: 41610-1G000
$204.70 MSRP: $287.60
You Save: $82.90 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Master Cylinder
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2005-2011 Hyundai Accent | High Grade, Middle Grade | DOHC - MPI | 3 Door Sedan, 4 Door Sedan, Sedan - 3Door 5P, Sedan - 4Door 5P
View related parts
Hyundai Accent Cylinder Assembly-Clutch Master
Part Number: 41610-1R110
$206.88 MSRP: $290.66
You Save: $83.78 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Master Cylinder
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2015-2017 Hyundai Accent | DOHC - GDI | Sedan - 4Door 5P, Sedan - 5Door 5P
View related parts
Hyundai Accent Cylinder Kit-Clutch Master
Part Number: 41660-22A00
$60.55 MSRP: $83.11
You Save: $22.56 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Replaced by: 41660-29B00
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1994-1999 Hyundai Accent | High Grade, Low Grade, Middle Grade | 3 Door, 4 Door
View related parts
Hyundai Accent Cylinder Kit-Clutch Master
Part Number: 41660-22A01
$74.70 MSRP: $104.95
You Save: $30.25 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Master Cylinder Repair Kit
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1994-1999 Hyundai Accent | High Grade, Low Grade, Middle Grade | 3 Door, 4 Door
View related parts
Hyundai Accent Cylinder Assembly-Clutch
Part Number: 41610-22050
Product Specifications
- Other Name: Cylinder Assembly-Clutch Master
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1994-1999 Hyundai Accent | High Grade, Low Grade, Middle Grade | 3 Door, 4 Door
View related parts
Hyundai Accent Cylinder Assembly-Clutch
Part Number: 41610-22060
Product Specifications
- Other Name: Cylinder Assembly-Clutch Master
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1994-1999 Hyundai Accent | High Grade, Low Grade, Middle Grade | 3 Door, 4 Door
View related parts
Hyundai Accent Cylinder Assembly-Clutch
Part Number: 41610-25010
Product Specifications
- Other Name: Cylinder Assembly-Clutch Master
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1999-2006 Hyundai Accent | Low Grade, Middle Grade | 3 Door Sedan, 4 Door Sedan
View related parts
Hyundai Accent Cylinder Assembly-Clutch
Part Number: 41610-25012
Product Specifications
- Other Name: Cylinder Assembly-Clutch Master
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1999-2006 Hyundai Accent | Low Grade, Middle Grade | 3 Door Sedan, 4 Door Sedan
View related parts
Hyundai Accent Cylinder Assembly-Clutch Master
Part Number: 41610-25013
Product Specifications
- Other Name: Master Cylinder
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 1999-2006 Hyundai Accent | Low Grade, Middle Grade | 3 Door Sedan, 4 Door Sedan

Hyundai Accent Clutch Master Cylinder

The Clutch Master Cylinder is found in Hyundai Accent cars and contributes to the formation of this pressure to pull the clutch when the clutch pedal is compressed. This component squeezes the hydraulic pressure to delivers the foot force so that the slave cylinder can pull the clutch off the flywheel. It is possible to identify the poor performing or faulty Clutch Master Cylinder through the following signs; Soft or spongy pedal, fluid leakage, shifting issues, and noises during engagement. Failure of seals or condition of cylinder bores can also be a cause of leakage at this area, which result to development of rust and other harms that affect the absorption of moisture in the hydraulic fluid. Hyundai Accent cars normally incorporate diagonally split hydraulic system since it is easy to control and in the case that one circuit fails the other will carry on.

If you are looking for affordable high-quality OEM Hyundai Accent Clutch Master Cylinder, then you have come to the prime place. Our website provides a large amount of genuine Hyundai Accent Clutch Master Cylinder at unbeatable prices. All our parts come backed with the manufacturer's warranty.

Hyundai Accent Clutch Master Cylinder Parts Questions & Experts Answers

Cylinder Assembly-Clutch Master
41610-1R100
Q: How to disconnect and remove the clutch master cylinder on Hyundai Accent?
A: Disconnect the negative cable from the battery. For 2011 and earlier models, raise the vehicle and support it securely on jackstands. Loosen the bleed plug on the release cylinder and place a drain pan under the bleeding plug. Apply the clutch pedal several times to force the hydraulic brake fluid out of the system. Continue to apply the clutch pedal until all fluid is expelled. Tighten the bleed plug securely. Caution: Don't allow hydraulic brake fluid to come into contact with paint as it will damage the finish. Disconnect the hydraulic line at the master cylinder. Have a small can and rags handy, as some residual fluid will be spilled as the line is removed. Working inside the vehicle, remove the cotter pin, washer, and clevis pin. Disconnect the pushrod from the clutch pedal. Working in the engine compartment, remove the nuts securing the master cylinder to the firewall and remove the master cylinder. For 2012 and later models, working in the vehicle under the dashboard, disconnect the push rod from the master cylinder by removing the snap pin and washer. Remove the four clutch pedal mounting nuts and pull the pedal assembly slightly forward. Remove the battery and the ECM. Working in the engine compartment, disconnect the release cylinder line and the reservoir hose from the clutch master cylinder. Remove the clutch master cylinder by turning it clockwise and pulling it from the firewall. Installation is the reverse of removal. Tighten the clutch master cylinder mounting bolts/nuts securely. Be sure to bleed the system.
