Q: How to remove and install the console for Hyundai Excel?
A: For models from 1986 through 1989, start by disconnecting the cable from the negative terminal of the battery, then remove the shift knob or handle, followed by the retaining screws, moving the seats forward if needed for access to the rear screws. Detach the console and lift it from the vehicle, with installation being the reverse of removal. For models from 1990 through 1994, slide the front seats forward, remove the retaining screws, and take out the rear console, then remove the shift knob or handle and the front console by unscrewing its retaining screws, with installation being the reverse of removal. For models from 1995 through 1999, position the front seats fully forward, remove the rear console mounting screws, and lift the rear console over the parking brake. For automatic transaxle models, remove the shift selector lever knob retaining screws, detach the overdrive shift connector, and remove the shift selector knob, while for manual transaxle models, unscrew the shift knob from the shaft. Remove the front console side and rear mounting screws, lift the front console, and disconnect the wiring from the power window switch if equipped, with installation being the reverse of removal. For models from 2000 through 2005, remove the two rear console mounting screws and pull off the rear console, then remove the shift control lever and the four front console mounting screws, lifting up the front console and disconnecting the electrical connectors, with installation being the reverse of removal. For models from 2006 through 2011, remove the front seats, pry out the small trim piece ahead of the shift lever to disconnect the electrical connector, remove the parking brake cover and console side covers, then remove the three console mounting bolts and the console itself, with installation being the reverse of removal. For models from 2012 and later, on manual transaxle models, use a plastic trim tool to pry up the shift lever trim cover, while on automatic transaxle models, remove the shift knob, pry up the shift cover, and disconnect the electrical connectors. Open the center console armrest to remove the tray cover and mounting screws, then remove the fasteners around the sides and top of the console, followed by the rear section. Use a trim tool to pry the console lower accessories panel out from the front, disconnect the electrical connectors, and remove the panel, then remove the fasteners around the sides and top of the console to take out the front section, with installation being the reverse of removal and replacing any damaged clips if necessary.
